Third stage


The upper stage that operates in space

The third stage can place the payload in LEO orbit from a wide range of altitude and orbit inclination.
skyrora third stage main

CHARACTERISTICS

  • Diameter 1.9 m
  • Length 1.4 m
  • Dry mass 314 kg
  • Loading mass 590 kg
  • Propellant HTP/Kerosene
  • Propellant feed system Pressure-fed
  • Thrust in a vacuum 3.5 kN
  • ISP in vacuum 305 s
  • Attitude control Electro actuator TVC in a
    wide range of inclination
    of orbits

technologies

  • Thrust vector control of pitch and yaw;
  • 3 axis cold gas attitude control;
  • Guidance, navigation and control system;
  • Carbon frame;
  • Screen-vacuum thermal insulation;
  • Possibility to install a dispenser;
  • Launch of a payload into orbit at an altitude of 500 km to 1000 km;
  • Characteristic speed, gained by a step of 1500 m/s.

advantage

The third stage is a capable and versatile orbital insertion vehicle, which enables Skyrora to deliver your payload, or group of payloads to right where you want to them. It is also adaptable to other launch vehicles, enabling Skyrora to enhance your mission capability from other launch sites too.
skyrora XL third stage carbon frame
